MT190XPRO3CN - Aluminum Tripod
Made after 2014-07-15
A1 Center Column Lock Knob
A2 Center Column Brake Shoe
B1 Main Casting Top Plate
B2 Main Casting Bottom Plate
C1 Left Side Pro Casting
C2 Pro Bushing
C3 Pro Rotation Bushing
C4 Right Side Pro Casting
C5 Bubble Level
D Center Column Assy
E USED Complete Leg Brace Assembly
E1 Leg Brace & Upper Leg Tube
E1 USED Leg Brace & Upper Leg Tube
E2 Leg Extender Release Button
E2 USED Leg Extender Release Button
F1 Upper Leg Clamp Assy
F2 Upper Snap Lever
F3 Clamp Screw
G Black Middle Leg Tube
G USED Black Middle Leg Tube
H1 Lower Leg Clamp Assy
H2 Lower Snap Lock Lever
H3 Clamp Screw
I Lower Leg Tube
I USED Lower Leg Tube
J1 Rubber Foot (set of 3)
J2 Spike Feet Accessory (set of 3)
J3 Suction Cup Feet Accessory (set of 3)
L Strap Loop
L USED Strap Loop
Editor note: Item numbers listed in the index on the right column may not be shown on the picture because the part may be obscured or is inside in underneath another part and cannot be shown. Click on the numbered link to see the actual part picture.
